GB713 Q345R is a Chinese standard boiler and pressure vessel steel plate, widely used in the manufacturing of boilers, pressure vessels, and other high-stress equipment.



1. Standard & Classification

Standard: GB713 (Chinese National Standard for boiler and pressure vessel plates, updated to GB/T 713.1-2023 as the latest version).

Material Grade: Q345R

"Q" stands for yield strength.

"345" indicates the minimum yield strength (345 MPa at room temperature).

"R" stands for "pressure vessel".



2. Heat Treatment & Processing

Hot-rolled or normalized (improves microstructure and impact toughness).

Post-weld heat treatment (PWHT) often required for thick plates to relieve stresses.



3. Comparison with Similar Grades

Q245R: Lower strength (245 MPa yield), used for less demanding applications.

Q370R: Higher strength (370 MPa yield), for heavier pressure equipment.

4. International Equivalents:

ASTM A516 Gr.60/70 (similar tensile strength, used in the US).

EN10028 P355QH (European standard).

5. Key Considerations

Weldability: Good, but requires preheating for thick sections (>32mm).

Temperature Range: Suitable for -20°C to 475°C (impact testing required for low temps).

6. Certification & Testing

Mandatory non-destructive testing (UT/RT) for critical applications.

Mill test certificates (MTC) must comply with GB713 standards.

1. Boilers: High/low-temperature components.

2. Pressure Vessels: Storage tanks, reactors, heat exchangers.

3. Other: Petrochemical equipment, nuclear power auxiliary systems.
